结直肠癌肝转移灶超声造影与 CT影像表现的比较

张小龙; 王文平; 黄备建; 丁红; 董怡; 陆清; 毛枫

结直肠癌肝转移灶超声造影与 CT影像表现的比较

张小龙¹,
王文平^1, ,,
黄备建¹,
丁红¹,
董怡¹,
陆清¹,
毛枫¹

复旦大学附属中山医院超声科,上海 200032

基金项目: 国家自然科学基金面上项目(编号:81371577)

计量
- 文章访问数: 2103
- HTML全文浏览量: 76
- PDF下载量: 1010
出版历程
- 刊出日期: 2016-02-24

Enhancement of Colorectal Carcinoma Liver Metastasis:Comparison of Contrast-Enhanced Ultrasound and Contrast-Enhanced Computed Tomography

Department of Ultrasound, Zhongshan Hospital, Fudan University, Shanghai 200032, China

摘要

摘要: 目的: 比较结直肠癌肝转移灶超声造影与增强CT血流灌注的异同。方法: 对比60例60个结直肠癌肝转移灶超声造影与增强CT动脉期及门脉期的增强表现。结果: 60个病灶超声造影动脉期均增强,53.3%(32/60)周边增强,46.7%(28/60)整体增强；增强CT见 78.3 %(47/60)的病灶周边增强,16.7%(10/60)整体增强,5%(3/60)未见增强(P＜0.01 )。动脉期病灶的增强程度方面,超声造影示93.3%(56/60)的病灶增强程度高于肝实质,6.7%(4/60)增强程度低于肝实质；增强CT示 91.2%(52/57)的病灶增强程度高于肝实质,8.8%(5/57)增强程度低于肝实质(P＞0.05)；门脉期,超声造影示100%(60/60)的病灶增强减退,较周围肝实质呈低回声,增强CT门脉期示 100%(60/60)的病灶较周围肝实质呈低密度,两种影像方法所示的转移灶增强程度均低于肝实质(P＞0.05)。结论: 结直肠癌肝转移灶的超声造影和增强CT增强表现不完全相同,超声造影在反映部分结直肠癌肝转移灶动脉血流灌注方面较增强CT有一定优势。
- 转移性肝癌 /
- 结直肠癌 /
- 超声检查 /
- 造影剂 /
- X-线断层摄影
Abstract: Objective: To compare blood perfusion visibility of contrast-enhanced ultrasound (CEUS) in colorectal carcinoma (CRC) liver metastasis with contrast-enhanced computed tomography (CECT). Methods: Sixty cases of CRC liver metastasis in Zhongshan Hospital, Fudan University were enrolled in this study and were analyzed with both CEUS and CECT. Results: At arterial phase, 53.3%(32/60) lesions showed rim-like enhancement and 46.7% (28/60) lesions showed total enhancement on CEUS,while on CECT, rim-like enhancement, total enhancement and no enhancement were detected in 78.3% (47/60) lesions, 16.7% (10/60) lesions and 5% (3/60) lesions lesions, respectively (P＜0.01). At peak enhancement, 93.3% (56/60) lesions showed higher enhancement and 6.7% (4/60) lesions showed lower enhancement on CEUS,which were detected in 91.2%(52/57) lesions and 8.8%(5/57) lesions at arterial phase of CECT, respectively (P＞0.05). At portal venous phase, all lesions showed lower enhancement on both CEUS and CECT (P＞0.05). Conclusions: The blood perfusion appearance of CRC liver metastasis with CEUS is not identical as that of CECT. Among some cases, CEUS is superior to CECT on arterial perfusion visualization of liver metastasis.
- Liver metastasis /
- Colorectal carcinoma /
- Ultrasonography /
- Contrast media /
- X-ray computed Tomography

HTML全文

参考文献(9)

[1]	Claudon M, Dietrich CF, Choi BI, et al.Guidelines and good clinical practice recommendations for Contrast Enhanced Ultrasound (CEUS) in the liver - update 2012:A WFUMB-EFSUMB initiative in cooperation with representatives of AFSUMB, AIUM, ASUM, FLAUS and ICUS[J].Ultrasound Med Biol, 2013,9(2):187-210.
[2]	Jemal A, Siegel R, Ward E, et al.Cancer statistics, 2006[J].CA Cancer J Clin, 2006,6(2):106-130.
[3]	高军, 张建立, 丁连安.结直肠癌肝转移的外科治疗[J].中国实用外科杂志, 2008,8(6):499-501.
[4]	李锐, 华兴, 张萍, 等.转移性肝癌动脉相增强的实时超声造影与增强螺旋CT比较研究[J].中国超声医学杂志, 2007,3(8):602-604.
[5]	Chiang SH, Thng CH, Teh CS, et al.Computed tomographic appearance of colorectal hepatic metastases[J].Ann Acad Med Singapore, 2003,2(2):191-195.
[6]	Massironi S, Conte D, Sciola V, et al.Contrast-enhanced ultrasonography in evaluating hepatic metastases from neuroendocrine tumours[J].Dig Liver Dis, 2010,2(9):635-641.
[7]	王文平, 李超伦, 丁红, 等.转移性肝癌的实时超声造影诊断[J].中华超声影像学杂志, 2008,7(2):127-129.
[8]	张会萍, 杜联芳, 何颖倩, 等.超声造影在转移性肝癌中的诊断价值[J].临床超声医学杂志, 2009,1(1):24-26.
[9]	李智岗, 黄景香, 李顺宗, 等.肝转移瘤的血供[J].北京大学学报:医学版, 2008,0(2):146-150.
